PQWT GT Series Long Range Water Detection Multi Channels Deep Depth 150m-3200m Option Ground Water Detector

  • Product name: Multi channels underground water detector
  • Application: auto-analysis of geological detection
  • Host weight: 1.95kg
  • Measuring time: 5-6min
  • Display: 10.1 inch HD display
  • Cable: 2.5m point pitch,10 line pitch, 54.7m in total length
  • Maximum number of channels: 18 channels
Get A Quote

PQWT GT Series Auto Analysis Geophysical Survey Equipment 3D Map Multi Channels Deep Depth Underground Water Detector

Product Description

The PQWT-GT Series is the 8th-generation of multi-channel prospecting instrument newly developed by our institute based on the principle of natural electric field frequency selection method. It is widely used in underground water sources, geological structures, mine veins, mine tunnels, cavities, karst caves, ant holes, mined-out areas, dam pipe surge, landslides and other fields. This series of instruments integrates 5 independent invention patents of PQWT, including data acquisition system, data processing system, automatic mapping system, auxiliary analysis system and circuit system. It realizes the simultaneous data acquisition of multi-channel and multi-frequency, completely solves the influence of unstable factors caused by the time difference of the natural electric field source, and greatly improves the accuracy and work efficiency. The instrument can process the collected data, automatically draw curve map, profile map, and 3D renderings in real time, and automatically analyze abnormal areas, so as to provide scientific basis for analyzing geological structures quickly and effectively.

ground water detector

compare to other similar machine.jpg


5 advantages.jpg


2 years
PQWT GT Series Underground Water Detector
Customized support
Place of Origin
Brand Name
Model Number
GT Seires
Product name
PQWT GT Series Ground Water Detector
Underground Water Detection
Borehole, geophysical prospecting and etc.
Power Supply
Rechargeable Lithium Battery
Detection type
Underground Structure
7 Inch LCD Touch Screen
Key words
Automatic Underground Water Detector
Max. number of channel
18 channels
Min. resolution

Packing & Delivery


Company Profile


Hunan Puqi Water Environment Institute Co. Ltd.  is a research institute specializing in researching and developing of geological exploration equipment.
